NOVAWINCH T-Series 3,500 Utility Winch (NVT 3500)
Novawinch T-Series is our workhorse series featuring proven parts and great performance. Novawinch's experience in building world class winches brings innovative concepts to this high-performance and affordable range without sacrificing reliability.
In this version, the solenoid is mounted above the winch motor.
Novawinch T-Series is our workhorse series featuring proven parts and great performance. Novawinch's experience in building world class winches brings innovative concepts to this high-performance and affordable range without sacrificing reliability.
In this version, the solenoid is mounted above the winch motor.
Novawinch T-Series is our workhorse series featuring proven parts and great performance. Novawinch's experience in building world class winches brings innovative concepts to this high-performance and affordable range without sacrificing reliability.
In this version, the solenoid is mounted above the winch motor.
The T-Series Lineup has all the features you want with the durability and reliability you need. With pulling capacities from 2500-4500lbs, the T series features an all-metal chassis engineered for long life and low maintenance. The Novawinch T-Series offers industrial winch performance in a compact package to conquer even the toughest situations.
Specifications
Rated Line Pull | 3,500lbs (1589kgs) single line |
Motor: | DC 12V: 2.4hp (1.8kW) |
Gear Box | 3-Stage Planetary |
Gear Ratio | 180:1 |
Clutch | Sliding ring gear |
Braking Action | Mechanical, Automatic load holding |
Fairlead | 4 Way Roller Fairlead |
Synthetic Rope | 3/16″ × 45.9′ (Φ4.8mm × 14m) |
Remote | Waterproof handheld remote 9.58' (3.0m) |
Dimensions | 13.62” x 4.53” x 6.3”(346mm x 115mm x 160mm) |
Mounting Bolt Pattern | 4.9″×3″(124mm × 76mm) |
Weight | 28.7lbs (13kgs) |
Performance
Line pull lbs(kgs) | No Load | Max Load |
Line speed FPM(MPM) | 13.7(4.2) | 5.6(1.7) |
Motor current Amps | 26 | 180 |
