NOVAWINCH T-Series 18,000 Winch (NVT 18000)
Novawinch T-Series is our workhorse series featuring proven parts and great performance. Novawinch's experience in building world class winches brings innovative concepts to this high-performance and affordable range without sacrificing reliability.
Novawinch T-Series is our workhorse series featuring proven parts and great performance. Novawinch's experience in building world class winches brings innovative concepts to this high-performance and affordable range without sacrificing reliability.
Novawinch T-Series is our workhorse series featuring proven parts and great performance. Novawinch's experience in building world class winches brings innovative concepts to this high-performance and affordable range without sacrificing reliability.
Features:
Classic design meets:
IP67 Rated Weatherproofing
Safety standards: SAE J706 and is CE marked.
Chrome-plated freespool pull and turn controls.
High-temperature, sealed contactor featuring silver contact pads for excellent conductivity and longevity.
Specifications
| Rated line pull: | 18000lbs(8165kgs)single line |
| Motor(Series wound): | DC 12V: 6.6hp/5.0kW DC 24V: 8.2hp/6.2kW |
| Gear train: | 4 stage planetary gear |
| Gear ratio: | 516:1 |
| Clutch: | Pull and turn |
| Braking action: | Mechanical,Automatic load holding |
| Fairlead: | 4-way roller fairlead |
| Wire rope: | 1/2″x82′(13mmx25m) |
| Drum size: | 3.46″×8.66″(88mm×220mm) |
| Dimensions: | 25.28″×8.46″×11.34″(642mm×215mm×288mm) |
| Bolt pattern: | 10″×4.5″(254mm×114mm) 10″×6.5″(254mm×165mm) |
| Net Weight: | 154lbs(70.2kgs) |
| 12V Performance | ||||||
|---|---|---|---|---|---|---|
| T-Series 18,000 | T-Series 15,000 | T-Series 12,500 | ||||
| Line pull lbs(kgs) | 0(0) | 18000(8165) | 0(0) | 15000(6804) | 0(0) | 12500(5670) |
| Line speed FPM(MPM) | 13.1(4.0) | 2.6(0.8) | 12.4(3.8) | 3.3(1.0) | 11.5(3.5) | 3.9(1.2) |
| Motor current Amps | 95 | 420 | 95 | 380 | 90 | 320 |
| 24V Performance | ||||||
|---|---|---|---|---|---|---|
| T-Series 18,000 | T-Series 15,000 | T-Series 12,500 | ||||
| Line pull lbs(kgs) | 0(0) | 18000(8165) | 0(0) | 15000(6804) | 0(0) | 12500(5670) |
| Line speed FPM(MPM) | 13.7(4.2) | 3.3(1.0) | 12.7(3.9) | 3.9(1.2) | 11.8(3.6) | 4.3(1.3) |
| Motor current Amps | 80 | 260 | 80 | 230 | 70 | 220 |
